Sliprings Blog
 |
|
| Brushless Slip Ring
It is common to incorporate the rotating interfaces in the Robotics and Mechanical system. Therefore, data and electrical power is required to pass though these interfaces. A Brush-less slip-ring is a kind of slip-ring which contains fluid metal to transmit signals and electrical power. |
|
 |
|
| Capsule Slip Ring
Capsule Slipring is a type of slipring which is used to transfer the data and electronic power between two contact surfaces where one surface is in static position and another is rotating. Therefore, when a footprints and low cost is an important consideration for the transmission of electirc power… |
|
 |
|
| Rotary Joint
A Rotary Joint which is also refereed as rotary union is a union that takes into consideration revolution of the unified parts. It is along these lines a gadget that gives a seal between a stationary inventory section and a turning part to allow the progression of a liquid into… |
|
 |
|
| Hybrid Slip-Ring
An electric slip-ring which is combined with fiber optic, coaxial, high frequency and rotary unions is known as Hybrid slip-ring. Automation and technological machine are communicating via industrial network in modern environment… |
|
 |
|
| Pin Slip-Ring
Pin slip ring stands apart with its little measurements, simple association and advantage of installation. There are different channels which are accessible ranges from 2 to 8 which are widely used and preferred in the machines of packaging… |
|
 |
|
| Fiber Optic Rotary Joints
Fiber Optic Rotary Joints (FORJs) are to optical signs, a way to pass signals across turning interfaces, especially when transmitting a lot of information. FORJs keep up the inherent points of interest of fiber start to finish… |
|
 |
|
| Miniature Slip Ring
Miniature slip rings are the smallest products of Capsule Slipring family. Outside diameters are between 6mm and 8mm. 2,4,6,8 and 12 channel models are available. Mini slip ring is specially designed for data and video signals transmission of small and medium-sized equipment… |
|
 |
|
| Through-bore Slip Ring
It is a very popular type of slip ring. It is better than classical slip ring because in classical slip ring it can only be mounted at the end of shaft but through-bore slip ring can be put at the end as well as over the shaft… |
|
 |
|
| Pancake Slip Ring
Pancake Slip Rings are intended for space-basic applications with respect to stature measurements. As the level shape is like a platter, they are likewise named level slip rings and platter slip rings. The Pancake Slip Rings with lodging are like the through-bore slip rings with … |
|
 |
|
| Joystick
The joystick is an input device consisting of a rod that turns towards a base and notifies the angle or direction of the device it controls. A joystick, otherwise called a control section, is the principle control gadget in the cockpit of numerous common and military airplane, for example, a focal switch or sidebar… |
|
